F&D W9 Bluetooth Speaker User Manual

1. تعارف

Thank you for choosing the F&D W9 5W Bluetooth Speaker. This manual provides essential information for the proper setup, operation, and maintenance of your device. Please read it thoroughly before use to ensure optimal performance and longevity of your speaker.

The F&D W9 is a compact and portable Bluetooth speaker designed for high-quality audio streaming. It features Bluetooth V5.0 for stable wireless connectivity, a 1.75-inch full-range neodymium driver for clear sound, and an IPX5 water-resistant design, making it suitable for various environments. It also supports TF card playback and AUX input for versatile music options.

2. پيڪيج مواد

مھرباني ڪري ھيٺ ڏنل شين لاءِ دٻي کي چيڪ ڪريو:

• F&D W9 Bluetooth Speaker
• USB ڪيبل (چارج ڪرڻ لاءِ)
• استعمال ڪندڙ جو دستياب (ھي دستاويز)

3. مصنوعات جون خاصيتون

• Bluetooth V5.0 Audio Streaming: Ensures stable and efficient wireless connection with compatible devices.
• پتلي ۽ پورٽبل ڊيزائن: Compact form factor for easy carrying.
• IPX5 Water-Resistant Design: Protects against splashes and light rain, suitable for outdoor use.
• 1.75-inch Full Range Neodymium Driver: صاف ۽ متحرڪ آڊيو پهچائي ٿو.
• Cloth Grill with Elegant Design: Enhances aesthetic appeal while protecting the speaker.
• Crystal and Natural Sound: Optimized audio output for an immersive listening experience.
• Passive Radiator Design: Provides enhanced, springy bass performance.
• TF ڪارڊ سپورٽ: Directly access and play music from a TransFlash (microSD) card.
• 3.5 ملي ميٽر آڪس ان پٽ: Connects to any music device using a standard audio cable.

4. ڪنٽرول ۽ اشارا

Familiarize yourself with the speaker's controls and indicators for seamless operation.

شڪل 4.1: مٿي View with Control Buttons

• پاور بٽڻ (O): Press and hold to power on/off. Short press to play/pause in Bluetooth/TF mode.
• آواز گھٽايو / پوئين ٽريڪ بٽڻ (-): حجم گهٽائڻ لاءِ مختصر دٻايو. پوئين ٽريڪ تي وڃڻ لاءِ ڊگهو دٻايو.
• حجم وڌايو / ايندڙ ٽريڪ بٽڻ (+): حجم وڌائڻ لاءِ مختصر دٻايو. ايندڙ ٽريڪ تي وڃڻ لاءِ ڊگهو دٻايو.
• موڊ بٽڻ (M): Short press to switch between Bluetooth, TF Card, and AUX modes.
• LED اشارو: Displays status (e.g., pairing, connected, charging).

شڪل 4.2: پاسي View with Port Cover

• چارجنگ پورٽ (USB): USB چارجنگ ڪيبل کي ڳنڍڻ لاءِ.
• TF ڪارڊ سلاٽ: For inserting a TransFlash (microSD) card.
• AUX ان پٽ (3.5mm): 3.5 ايم ايم آڊيو ڪيبل ذريعي ٻاهرين آڊيو ڊوائيسز کي ڳنڍڻ لاءِ.
• Note: The charging port, TF card slot, and AUX input are located under a protective flap to maintain water resistance. Ensure the flap is securely closed when not in use, especially near water.

5. سيٽ اپ

5.1 شروعاتي چارجنگ

1. پهرين استعمال کان اڳ، اسپيڪر کي مڪمل طور تي چارج ڪريو.
2. اسپيڪر جي پاسي واري حفاظتي فليپ کي کوليو.
3. Connect the provided USB cable to the speaker's charging port and the other end to a USB power adapter (not included) or a computer's USB port.
4. ايل اي ڊي انڊيڪيٽر چارجنگ اسٽيٽس ڏيکاريندو (مثال طور، چارج ڪرڻ دوران ڳاڙهو، مڪمل چارج ٿيڻ تي بند).
5. Once fully charged, disconnect the cable and securely close the protective flap.

5.2 پاور آن/آف

• پاور آن ڪرڻ: پاور بٽڻ کي دٻايو ۽ رکو (O) for approximately 3 seconds until you hear an audible prompt and the LED indicator lights up.
• پاور آف ڪرڻ: پاور بٽڻ کي دٻايو ۽ رکو (O) for approximately 3 seconds until you hear an audible prompt and the LED indicator turns off.

6. آپريٽنگ هدايتون

6.1 بلوٽوٽ جوڙي

1. Power on the F&D W9 speaker. It will automatically enter Bluetooth pairing mode, indicated by a flashing LED.
2. پنهنجي بلوٽوٿ-فعال ڊوائيس (اسمارٽ فون، ٽيبليٽ، وغيره) تي، بلوٽوٿ سيٽنگز ڏانهن وڃو ۽ بلوٽوٿ کي فعال ڪريو.
3. ڳولھيو available devices. You should see "F&D W9" in the list.
4. Select "F&D W9" to connect. Once successfully paired, the speaker will give an audible confirmation, and the LED indicator will stop flashing and remain solid.
5. You can now play audio from your device through the F&D W9 speaker.

6.2 TF ڪارڊ پلے بیک

1. پڪ ڪريو ته اسپيڪر پاور آهي.
2. اسپيڪر جي پاسي واري حفاظتي فليپ کي کوليو.
3. MP3 آڊيو سان گڏ هڪ TF (مائڪرو ايس ڊي) ڪارڊ داخل ڪريو files TF ڪارڊ سلاٽ ۾.
4. The speaker will automatically switch to TF card mode and begin playing music. If it does not, short press the Mode button (M) to switch to TF card mode.
5. Use the Volume Up/Down buttons (+ / -) for track navigation (long press) and volume control (short press).
6. Securely close the protective flap when done.

6.3 AUX ان پٽ

1. پڪ ڪريو ته اسپيڪر پاور آهي.
2. اسپيڪر جي پاسي واري حفاظتي فليپ کي کوليو.
3. 3.5mm آڊيو ڪيبل جي هڪ پڇاڙي (شامل نه آهي) کي اسپيڪر تي AUX ان پٽ پورٽ سان ڳنڍيو.
4. 3.5 ايم ايم آڊيو ڪيبل جي ٻئي ڇيڙي کي پنهنجي ٻاهرين ڊوائيس (مثال طور، ايم پي 3 پليئر، ڪمپيوٽر) جي آڊيو آئوٽ پٽ جيڪ سان ڳنڍيو.
5. موڊ بٽڻ کي مختصر دٻايو (M) AUX موڊ تي سوئچ ڪرڻ لاءِ.
6. پنهنجي ٻاهرين ڊوائس تان آڊيو هلايو. آواز کي اسپيڪر يا ڳنڍيل ڊوائس ذريعي ڪنٽرول ڪري سگهجي ٿو.
7. Securely close the protective flap when done.

7. سار سنڀال

Proper care ensures the longevity of your F&D W9 speaker:

• صفائي: Use a soft, dry cloth to clean the speaker. Do not use abrasive cleaners, waxes, or solvents.
• پاڻي جي مزاحمت: The speaker is IPX5 water-resistant, meaning it can withstand splashes and light rain. Do not submerge the speaker in water or expose it to strong jets of water. Always ensure the protective flap covering the ports is securely closed when near water.
• اسٽوريج: اسپيڪر کي سڌي سج جي روشني ۽ انتهائي گرمي پد کان پري ٿڌي، سڪل جاءِ تي رکو.
• بيٽري جي سنڀال: To preserve battery life, avoid fully discharging the battery frequently. If storing for a long period, charge the speaker to about 50% every few months.
• اثرات کان بچڻ: Do not drop or subject the speaker to strong impacts, as this can damage internal components.

8. مسئلا حل ڪرڻ

If you encounter issues with your F&D W9 speaker, refer to the following common problems and solutions:

If the problem persists after trying these solutions, please contact F&D customer support.

9. وضاحتون

10. وارنٽي ۽ سپورٽ

The F&D W9 Bluetooth Speaker comes with a 1 سال وارنٽي خريداري جي تاريخ کان. مھرباني ڪري پنھنجي خريداري جي رسيد کي وارنٽي جي ثبوت طور رکو.

This warranty covers manufacturing defects and issues arising from normal use. It does not cover damage caused by misuse, accidents, unauthorized modifications, or failure to follow the instructions in this manual.

For warranty claims, technical support, or any inquiries regarding your F&D W9 speaker, please contact:

FENDA AUDIO (INDIA) PVT. LTD.
8/41, 1st & 2nd Floor, Kirti Nagar Indl. Area,
نئين دهلي-110015، انڊيا

Please visit the official F&D webسائيٽ تي وڃو يا انهن جي ڪسٽمر سروس سان رابطو ڪريو جديد ترين سپورٽ معلومات لاءِ.
