ھدايت وارو دستور

1. تعارف

خريد ڪرڻ لاءِ مهربانيasing the TANLANIN Vintage Bluetooth Vinyl Record Player. This portable suitcase-style record player is designed to provide a versatile audio experience, allowing you to enjoy your vinyl collection, stream music wirelessly via Bluetooth, record vinyl to USB/SD, and connect to various audio devices. Please read this manual thoroughly before use to ensure proper operation and to maximize your enjoyment of the product.

2. اهم حفاظتي ڄاڻ

• يونٽ کي هلائڻ کان پهريان سڀ هدايتون پڙهو.
• مستقبل جي حوالي لاءِ هي دستياب رکو.
• يونٽ کي مينهن يا نمي کي ظاهر نه ڪريو.
• ڪنهن به وائنٽيليشن جي افتتاح کي بلاڪ نه ڪريو.
• ٺاهيندڙ طرفان بيان ڪيل صرف منسلڪ / لوازمات استعمال ڪريو.
• بجليءَ جي طوفانن دوران يا ڊگھي عرصي لاءِ غير استعمال ٿيڻ دوران يونٽ کي انپلگ ڪريو.
• سڀني خدمتن جو حوالو ڏيو قابل خدمت اهلڪارن ڏانهن.

3. پيڪيج مواد

پڪ ڪريو ته سڀئي شيون پيڪيج ۾ موجود آهن:

• TANLANIN Vintage Bluetooth Vinyl Record Player
• پاور يونٽ
• 45 آر پي ايم اڊاپٽر
• Spare Needle
• سِپچي
• Users Manual (this document)

4. پراڊڪٽ ختمview

Familiarize yourself with the components of your record player.

شڪل 4.1: مجموعي طور view of the TANLANIN Vintage Bluetooth Vinyl Record Player.

Figure 4.2: Rear and side panel connections including RCA output, Aux input, and Headphone Jack.

Figure 4.3: Control panel with USB port, TF card slot, and recording buttons.

5. سيٽ اپ

1. پيڪنگ کولڻ: Carefully remove the record player from its packaging. Retain all packaging materials for future transport or storage.
2. لڳائڻ: يونٽ کي سڌي سج جي روشني، گرمي جي ذريعن، ۽ گهڻي مٽي يا وائبريشن کان پري هڪ فليٽ، مستحڪم مٿاڇري تي رکو.
3. پاور ڪنيڪشن: Connect the provided power unit to the DC IN port on the back of the record player and then plug it into a wall outlet.
4. حفاظتي ڍڪ هٽايو: Remove the white protective cover from the stylus (needle) before playing any records.
5. Platter Protection: Remove the white foam pad from the turntable platter. Place the included slipmat on the platter.

6. آپريٽنگ هدايتون

6.1 ونائل رڪارڊ کيڏڻ

1. Open the record player lid.
2. ٽرن ٽيبل پليٽر تي ونائل رڪارڊ رکو. جيڪڏهن 45 RPM سنگل کيڏي رهيا آهيو، ته 45 RPM اڊاپٽر کي سينٽر اسپنڊل تي رکو.
3. اسپيڊ چونڊيندڙ سوئچ استعمال ڪندي مناسب رفتار (33، 45، يا 78 RPM) چونڊيو.
4. Turn the Power Switch/Volume Knob clockwise to power on the unit.
5. ٽون آرم ڪلپ جاري ڪريو.
6. ڪيو ليور استعمال ڪندي ٽون بازو کي نرميءَ سان مٿي ڪريو ۽ اسٽائلس کي رڪارڊ جي گهربل ٽريڪ تي رکو.
7. Lower the tone arm slowly using the cue lever. The record will begin to play.
8. Adjust the volume to your desired level using the Power Switch/Volume Knob.
9. At the end of the record, the turntable will automatically stop if the Auto-Stop switch is in the ON position. Lift the tone arm and return it to the tone arm rest.

Figure 6.1: Playing a vinyl record on the turntable.

6.2 بلوٽوٿ پلے بیک

1. رڪارڊ پليئر آن ڪريو.
2. Press the 'M' button on the control panel to switch to Bluetooth mode. The LED display will show 'BT'.
3. Enable Bluetooth on your mobile device (smartphone, tablet, etc.) and search for 'TE-012'.
4. Select 'TE-012' to pair. Once paired, you will hear a confirmation sound.
5. Start playing music from your device. The audio will stream through the record player's built-in speakers.

Figure 6.2: Wireless music playback via Bluetooth connection.

6.3 USB/SD Recording

1. Insert a USB drive or SD card into the corresponding slot on the control panel.
2. Play a vinyl record as described in Section 6.1.
3. Long press the 'M' button to start recording. The LED display will show 'REC' and a timer.
4. To stop recording, long press the 'M' button again. The recording will be saved as an MP3 or WAV file توهان جي USB ڊرائيو يا SD ڪارڊ تي.

6.4 AUX ان پٽ

Connect external audio devices (e.g., MP3 player, CD player) to the AUX IN port using a 3.5mm audio cable. The audio from the external device will play through the record player's speakers.

6.5 آر سي اي آئوٽ

To connect the record player to external powered speakers or an amplifier, use an RCA cable (not included) to connect the RCA OUT jacks on the back of the unit to the audio input of your external audio system.

6.6 هيڊ فون جيڪ

For private listening, plug headphones into the 3.5mm headphone jack on the front of the unit. The built-in speakers will be muted automatically.

7. سار سنڀال

• اسٽائلس جي صفائي: Use a soft brush to gently clean the stylus from back to front. Do not use excessive force.
• يونٽ جي صفائي: Wipe the exterior of the unit with a soft, dry cloth. Do not use harsh chemicals or abrasive cleaners.
• رڪارڊ جي سنڀال: Keep your records clean and free of dust to ensure optimal sound quality and prolong the life of your stylus.
• اسٽائلس جي متبادل: The stylus is a consumable part and should be replaced after approximately 300-500 hours of use. Refer to the manufacturer's guidelines for replacement stylus models.

8. مسئلا حل ڪرڻ

9. وضاحتون

10. وارنٽي ۽ سپورٽ

This product comes with a standard manufacturer's warranty. For specific warranty details, please refer to the warranty card included in your package or contact TANLANIN customer support. If you encounter any issues or have questions regarding your record player, please reach out to our customer service team for assistance.
