1. تعارف
Thank you for choosing the Glen 6090 Portable Ductless Kitchen Chimney. This appliance is designed to effectively remove cooking fumes and odors, providing a cleaner kitchen environment. Its compact and portable design makes it suitable for various cooking setups, including induction, infrared, and grills. Please read this manual thoroughly before operating the appliance to ensure safe and efficient use.
2. حفاظتي هدايتون
- بجلي جي فراهمي کي يقيني بڻائيtage matches the specifications of the appliance (230 Volts AC).
- Do not immerse the chimney in water or any other liquid.
- Keep the appliance away from direct heat sources and open flames.
- Always unplug the chimney from the power outlet before cleaning or performing any maintenance.
- آپريشن دوران هوا جي داخل ٿيڻ يا نڪرڻ واري وينٽس کي نه روڪيو.
- هي اوزار صرف گهريلو استعمال لاءِ آهي. ان کي تجارتي يا صنعتي مقصدن لاءِ استعمال نه ڪريو.
- ٻارن جي پهچ کان پري رکو.
- جيڪڏهن پاور هارڊ خراب ٿئي ٿي، ان کي ٺاهيندڙ، ان جي سروس ايجنٽ، يا ساڳئي طرح قابل ماڻهن طرفان تبديل ڪيو وڃي ته جيئن خطري کان بچڻ لاء.
3. پراڊڪٽ ختمview
The Glen 6090 Portable Ductless Kitchen Chimney features a sleek, modern design with powerful suction and a multi-layer filtration system to capture grease and odors effectively.
Figure 1: Glen 6090 Portable Chimney in a kitchen setting, demonstrating its compact size and powerful suction.
Figure 2: Glen 6090 Portable Chimney in a kitchen with a family cooking, highlighting its use during meal preparation.
اهم خاصيتون:
- 3-پرت فلٽريشن سسٽم: Equipped with Carbon, Aluminium, and Polymer filters for effective fume and odor filtration.
- ڪمپيڪٽ ۽ پورٽبل: Designed for easy placement on any tabletop or countertop.
- Removable Oil Collector Cup: Gathers filtered residual grease and oil for easy disposal.
- Non-Slip Silicone Base: Ensures stability and prevents movement during use.
- ٻه رفتار جا درجا: Easily adjustable suction power.
- سنگل بٽڻ آپريشن: Simple and intuitive control.
شڪل 3: ڌماڪو ٿيو view of the 3-layer filtration system (Carbon, Aluminum, Polymer filters).
Figure 4: Magnetic filter holder for easy filter removal and installation.
Figure 5: Removable oil collecting cup.
Figure 6: Non-slip pads on the base for stability.
شڪل 7: جڳهه جي حوالي لاءِ پراڊڪٽ جا طول و عرض.
4. سيٽ اپ
The Glen 6090 Portable Ductless Kitchen Chimney requires no complex installation. It is designed for immediate use after power connection.
- Unpack the chimney and all its components.
- Place the chimney on a stable, flat, and heat-resistant surface near your cooking area. Ensure the non-slip base is securely positioned.
- Ensure the oil collector cup is correctly inserted into its designated slot.
- Plug the power cord into a suitable 230V AC power outlet.
5. آپريشن
Operating your Glen 6090 Portable Chimney is straightforward with its single-button control.
- پاور آن / آف: Press the power button located on the unit to turn the chimney on or off. The button will illuminate when the unit is active.
- رفتار کي ترتيب ڏيڻ: The chimney features two speed levels. Press the power button once for the first speed, and press it again for the second, higher speed. A third press will turn the unit off.
- پوزيشن: For optimal smoke extraction, position the chimney so that its intake vent is directly above or very close to the source of cooking fumes.
Video 1: A demonstration of the Glen 6090 Portable Chimney's features, including its compact design, 3-layer filtration system, non-slip base, single-button operation, and removable oil collector cup. It shows the chimney in use with grilling and frying.
6. سار سنڀال ۽ صفائي
Regular cleaning and maintenance ensure the longevity and efficiency of your chimney.
- بجلي بند: Always unplug the chimney before cleaning.
- Cleaning the Oil Collector Cup: The removable oil collector cup should be emptied and cleaned regularly, depending on usage. Pull out the cup, wash it with warm soapy water, rinse, and dry thoroughly before reinserting.
- صفائي فلٽر: The 3-layer filters (Carbon, Aluminium, Polymer) should be cleaned periodically. To remove, gently detach the filter holder and then remove each filter. Wash the filters with warm soapy water, rinse thoroughly, and allow them to dry completely before reassembling.
- ٻاهرين صفائي: Wipe the exterior of the chimney with a soft, damp ڪپڙو. استعمال نه ڪريو abrasive cleaners يا solvents.
7. مسئلا حل ڪرڻ
| مسئلو | ممڪن سبب | حل |
|---|---|---|
| Chimney does not turn on | No power supply; Power cord not plugged in; Faulty power outlet | Check power connection; Try a different outlet; Contact customer service |
| گھٽ سکشن پاور | Filters are clogged; Chimney positioned too far from cooking source | Clean or replace filters; Reposition the chimney closer to the cooking area |
| آپريشن دوران غير معمولي شور | Loose components; Obstruction in the fan | Check for loose parts; Ensure no foreign objects are in the fan area; Contact customer service |
| Oil collector overflowing | Oil collector not emptied regularly | Empty and clean the oil collector more frequently |
8. وضاحتون
| خاصيت | تفصيل |
|---|---|
| ماڊل | سي 6090 |
| برانڊ | گلن |
| چڙهڻ جو قسم | ڊائريڪٽنگ |
| وائنٽيليشن جو قسم | نلڪي |
| ايئر فلو بي گھرڻ | 285 سي ايم ايڇ |
| شور جي سطح | 58 ڊيسيبل |
| رفتار جو تعداد | 2 |
| فلٽر جو قسم | Carbon, Aluminium & Polymer filter |
| ڪنٽرولن جو قسم | دٻايو بٽڻ |
| جلدtage | 230 وولٽ (AC) |
| سالياني توانائي واپرائڻ | 230 ڪلواٽ ڪلاڪ في سال |
| شيءِ جو وزن | 1 ڪلو 350 گرام |
| پيداوار جي ماپ (LxWxH) | 21 x 30 x 35 سينٽي ميٽر |
| شامل اجزاء | چمني |
9. وارنٽي ۽ سپورٽ
Glen Appliances Pvt. Ltd. provides a standard warranty for this product. For detailed warranty terms and conditions, please refer to the warranty card included with your purchase or visit the official Glen website. For any technical assistance, service requests, or inquiries, please contact Glen customer support.
ٺاهيندڙ: Glen Appliances Pvt. لميٽيڊ
ائڊريس: Plot no.919 sector 68 IMT Faridabad Haryana -121008
