VISLONE 300W Electric Paint Sprayer User Manual

1. اھم حفاظتي ھدايتون

هن پاور اوزار سان مهيا ڪيل سڀئي حفاظتي ڊيڄاريندڙ، هدايتون، عڪس، ۽ وضاحتون پڙهو. هيٺ ڏنل فهرستن جي سڀني هدايتن تي عمل ڪرڻ ۾ ناڪامي ٿي سگھي ٿي برقي جھٽڪو، باهه، ۽/يا سنگين زخمي.

• ڪم واري علائقي جي حفاظت: ڪم واري علائقي کي صاف ۽ چڱي طرح روشن رکو. بجلي جا اوزار ڌماڪيدار ماحول ۾ نه هلايو، جهڙوڪ ٻرندڙ مائع، گئس، يا مٽي جي موجودگي ۾.
• برقي حفاظت: پاور ٽول پلگ کي آئوٽ ليٽ سان ملائڻ گهرجي. ڪڏهن به پلگ کي ڪنهن به طرح سان تبديل نه ڪريو. مٽي يا زميني سطحن سان جسم جي رابطي کان پاسو ڪريو.
• ذاتي حفاظت: Always wear eye protection, respiratory protection, and appropriate clothing. Do not overreach. Maintain proper footing and balance at all times.
• اوزار استعمال ۽ سنڀال: پاور ٽول کي زور سان نه لڳايو. پنهنجي ايپليڪيشن لاءِ صحيح پاور ٽول استعمال ڪريو. ڪا به ترتيب ڏيڻ، لوازمات تبديل ڪرڻ، يا پاور ٽولز کي ذخيرو ڪرڻ کان اڳ پاور سورس کان پلگ ڊسڪنيڪٽ ڪريو.
• Specific Sprayer Safety: Ensure proper ventilation when spraying. Do not spray flammable materials near open flames or ignition sources. Always clean the sprayer thoroughly after each use.

2. پراڊڪٽ ختمview ۽ پيڪيج مواد

The VISLONE 300W Electric Paint Sprayer is designed for efficient application of various coatings. Familiarize yourself with its components and ensure all items are present.

شڪل 2.1: ختمview of the VISLONE 300W Electric Paint Sprayer.

2.1 Package List:

• 1 x پينٽ اسپريئر
• 2 x بيٽري (1300mAh)
• 1 x صفائي برش
• 1 x صفائي جي سوئي
• 4 x Nozzles (Φ1.0mm, 1.8mm, 2.0mm, 2.5mm)
• 3 ايڪس گيسٽڪ
• 1 x Viscosity Cup
• 1 x استعمال ڪندڙ دستياب (هي دستاويز)
• 1 x چارجر

3. سيٽ اپ ۽ اسيمبلي

3.1 رنگ تيار ڪرڻ

1. Ensure the paint or coating material is suitable for spray application.
2. Use the provided viscosity cup to check the paint's viscosity. Thin the paint with the appropriate solvent (water for latex, mineral spirits for oil-based) until it passes through the viscosity cup within the recommended time (refer to paint manufacturer's instructions).
3. Strain the thinned paint to remove any lumps or debris that could clog the nozzle.

3.2 اسپرير کي گڏ ڪرڻ

1. Attach the paint container (800ml tank) to the sprayer body by screwing it securely.
2. Insert a charged battery into the battery slot at the base of the handle until it clicks into place.

Figure 3.1: The 800ml capacity paint tank attached to the sprayer.

3.3 Selecting and Installing Nozzles

The sprayer includes four copper nozzles of different sizes (Φ1.0mm, 1.8mm, 2.0mm, 2.5mm) for various paint types and project requirements.

1. Choose the appropriate nozzle size for your paint and desired finish. Generally, smaller nozzles are for thinner materials and finer finishes, while larger nozzles are for thicker materials and faster coverage.
2. Unscrew the nozzle cap from the front of the sprayer.
3. Insert the selected nozzle and ensure a gasket is properly seated.
4. Screw the nozzle cap back on securely.

Figure 3.2: The four interchangeable copper nozzles (1.0mm, 1.8mm, 2.0mm, 2.5mm).

3.4 Adjusting Spray Patterns

The sprayer offers three spray patterns: horizontal, vertical, and circular. Rotate the air cap to select the desired pattern.

• افقي: مٿي ۽ هيٺ اسپري ڪرڻ لاءِ.
• عمودي: پاسي کان پاسي حرڪت ڪرڻ لاءِ اسپري ڪرڻ لاءِ.
• گردش: For small areas or detailed work.

4. آپريشن

4.1 Powering On and Testing

1. Ensure the sprayer is fully assembled and the paint tank is filled.
2. Point the sprayer at a test surface (e.g., cardboard) and press the trigger to start spraying.
3. Adjust the flow control knob on the sprayer to achieve the desired paint output. The flow rate can be adjusted between 500-800ml/min.

Figure 4.1: Adjusting the flow control and selecting spray patterns (circular, horizontal, vertical).

4.2 اسپري ڪرڻ جي ٽيڪنڪ

• Maintain a consistent distance (typically 6-12 inches) from the surface being painted.
• اسپريئر کي هموار، هڪجهڙا اسٽروڪ ۾ هلايو، هر پاس کي تقريباً 50٪ اوورليپ ڪندي هڪجهڙائي ڪوريج کي يقيني بڻايو وڃي.
• رنگ جي ٺهڻ کان بچڻ لاءِ هر اسٽروڪ جي آخر ۾ ٽرگر کي ڇڏي ڏيو.
• بهترين نتيجن لاءِ، هڪ ٿلهي ڪوٽ جي بدران ڪيترائي ٿلها ڪوٽ لڳايو.

شڪل 4.2: مثالamples of the paint sprayer's application on furniture, walls, cars, and fences.

5. سار سنڀال ۽ صفائي

Proper cleaning after each use is essential to ensure the longevity and optimal performance of your paint sprayer.

5.1 صفائي لاءِ ڌار ڪرڻ

1. Disconnect the battery from the sprayer.
2. Unscrew the paint container and empty any remaining paint.
3. Unscrew the nozzle cap and remove the nozzle and gasket.
4. The front section of the sprayer can be easily detached from the motor housing for thorough cleaning.

Figure 5.1: The sprayer's design allows for easy disassembly for cleaning.

5.2 صفائي جي طريقيڪار

1. Fill the paint container with the appropriate cleaning solution (water for water-based paints, solvent for oil-based paints).
2. ڪنٽينر کي ٻيهر ڳنڍيو ۽ صفائي واري محلول کي اسپرير ذريعي اسپري ڪريو جيستائين اهو صاف نه ٿئي.
3. Thoroughly clean all disassembled parts (nozzle, gasket, container, suction tube) using the provided cleaning brush and needle.
4. Wipe down the exterior of the sprayer with a damp ڪپڙو.
5. Allow all parts to dry completely before reassembly or storage.

5.3 اسٽوريج

Store the clean, dry sprayer in a cool, dry place, away from direct sunlight and extreme temperatures. Ensure the battery is removed if storing for extended periods.

6. مسئلا حل ڪرڻ

7. وضاحتون

Figure 7.1: Dimensions of the VISLONE 300W Electric Paint Sprayer.

8. وارنٽي ۽ سپورٽ

For warranty information or technical support, please refer to the contact details provided by your retailer or visit the official VISLONE webسائيٽ. خريداري جي ثبوت طور پنهنجي خريداري جي رسيد رکو.

توھان جو دورو ڪري سگھو ٿا VISLONE Store on Amazon وڌيڪ معلومات لاءِ.
