آئي ڪي ملٽي ميڊيا آئي رگ مائڪ يوزر مينوئل

تعارف

The iRig Mic is a handheld condenser microphone designed for use with mobile devices such as iPhone, iPod touch, iPad, and Android devices. It enables professional audio and vocal recordings in various environments, from studio to field. The microphone features a highly unidirectional condenser-electret capsule for quality recording, real-time monitoring via a dual mini-jack connector, and a three-level gain switch for adjusting to different sound pressure levels. Its robust metal construction ensures durability for mobile use.

Image: The iRig Mic handheld condenser microphone, showcasing its design and integrated cable.

دٻي ۾ ڇا آهي

The iRig Mic package includes the following components:

• iRig High-quality Handheld Microphone for Smartphones & Tablets
• 1/8'' TRRS tethered cable for device connection
• Microphone stand clamp
• Carrying pouch for portability
• 5/8" to 3/8" thread adapter for various mic stands
• Access to virtual video and audio applications

سيٽ اپ ڪريو

1. ڊوائيس سان ڳنڍيو: Plug the 1/8'' TRRS tethered cable from the iRig Mic into the headphone/microphone jack of your mobile device (iPhone, iPad, iPod Touch, or Android device).
2. هيڊ فون مانيٽرنگ: The iRig Mic features a dual mini-jack connector. If you wish to monitor your audio in real-time, connect your headphones to the secondary mini-jack on the microphone.
3. چڙهڻ (اختياري): For hands-free operation, attach the iRig Mic to a standard microphone stand using the included mic stand clamp. The 5/8" to 3/8" thread adapter can be used for compatibility with different stand types.

Image: The iRig Mic connected to a smartphone, illustrating the 3.5mm TRRS connection and the headphone output.

Image: The iRig Mic securely attached to a microphone stand using the provided clamp، استعمال لاءِ تيار.

آپريٽنگ هدايتون

1. Gain Level Adjustment: The iRig Mic features a three-level gain switch located on its body. Adjust this switch based on the sound source's volume:
   • گھٽ: For loud sound sources (e.g., loud singing, instruments).
   • وچولي: For general vocals and speaking.
   • اعلي: For soft speaking or distant sound sources.
   Ensure the gain is set appropriately to prevent distortion or insufficient volume.
2. ايپليڪيشن استعمال: Open your preferred audio or video recording application on your mobile device. The iRig Mic is compatible with a wide range of apps, including IK Multimedia's VocaLive and AmpliTube (free versions available). Select the iRig Mic as your input device within the app settings if necessary.
3. حقيقي وقت جي نگراني: If headphones are connected to the iRig Mic's dual mini-jack, you will hear your audio input in real-time, allowing for immediate adjustments to your performance or gain settings.
4. مائڪروفون لڳائڻ: For optimal sound quality, position the microphone appropriately for your sound source. For vocals, hold the microphone close to the mouth. For instruments or ambient sound, adjust distance and angle as needed. The unidirectional pattern helps in reducing background noise.

تصوير: هڪ تفصيلي view of the iRig Mic, highlighting the three-level gain switch for adjusting input sensitivity.

Image: The iRig Mic connected to a smartphone or tablet, demonstrating its use with a music application.

Image: A user singing into the iRig Mic, illustrating its primary use for vocal performances.

سار سنڀال

• صفائي: Use a soft, dry cloth to clean the exterior of the microphone. Avoid using liquid cleaners or abrasive materials, as these can damage the finish or internal components.
• اسٽوريج: When not in use, store the iRig Mic in its carrying pouch to protect it from dust, moisture, and physical damage.
• سنڀالڻ: Despite its rugged metal body, avoid dropping the microphone or subjecting it to excessive force, which could affect its performance or internal wiring.
• ڪيبل جي سنڀال: Do not sharply bend or crimp the tethered cable. Store it loosely coiled to prevent damage.

مشڪلاتون

ڪوبه آواز يا گهٽ حجم:

• Ensure the iRig Mic's TRRS cable is fully inserted into your device's headphone/microphone jack.
• Check the three-level gain switch on the microphone and adjust it to a higher setting if the sound source is quiet.
• Verify the input settings within your recording application. Ensure the iRig Mic is selected as the audio input.
• Increase the input volume within your recording application or device settings.
• If using headphones for monitoring, ensure they are properly connected to the iRig Mic's output jack and that their volume is up.

مسخ ٿيل آواز:

• Lower the three-level gain switch on the microphone if the sound source is very loud.
• Reduce the input volume within your recording application or device settings.
• Ensure the microphone is not too close to the sound source, especially for loud vocals or instruments.

Microphone Not Recognized by Device/App:

• Confirm the TRRS cable is fully seated in the device's jack.
• Restart your mobile device and the recording application.
• پڪ ڪريو ته توهان جي ڊوائيس جو آپريٽنگ سسٽم جديد آهي.
• Test the microphone with a different compatible application to rule out app-specific issues.

وضاحتون

وارنٽي ۽ سپورٽ

For warranty information and technical support, please refer to the official IK Multimedia webسائيٽ يا جامع يوزر مينوئل جيڪو PDF فارميٽ ۾ موجود آهي.

سرڪاري استعمال ڪندڙ دستورالعمل (PDF): PDF Manual ڊائون لوڊ ڪريو

For further assistance, contact IK Multimedia customer support directly.
