Eaton 3S 550 VA Desktop Standby UPS User Manual

1. تعارف

This manual provides essential information for the safe and efficient operation of your Eaton 3S 550 VA Desktop Standby Uninterruptible Power Supply (UPS). The Eaton 3S UPS is designed to protect your electronic equipment from power outages, surges, and sags, ensuring continuous operation and data integrity during power disturbances. Please read this manual thoroughly before installation and use.

2. حفاظت جي ڄاڻ

Observe the following safety precautions to prevent injury and damage to the UPS or connected equipment.

• برقي حفاظت: Connect the UPS to a properly grounded AC power outlet. Do not remove the grounding prong.
• صرف اندروني استعمال: This UPS is intended for indoor use in a controlled environment. Avoid exposure to moisture, extreme temperatures, or direct sunlight.
• وينٽيليشن: UPS جي چوڌاري مناسب هوا جي وهڪري کي يقيني بڻايو. وينٽيليشن جي سوراخن کي نه روڪيو.
• بيٽري جي حفاظت: The UPS contains a sealed lead-acid battery. Do not attempt to open or service the battery yourself. Refer to qualified service personnel for battery replacement. Dispose of batteries properly according to local regulations.
• مائع ۽ پرڏيهي شيون: Do not allow liquids or foreign objects to enter the UPS.
• اوور لوڊ: Do not overload the UPS outlets. Refer to the specifications section for maximum load capacity.

3. پيڪيج مواد

پڪ ڪريو ته سڀئي شيون پيڪيج ۾ موجود آهن:

• Eaton 3S 550 VA Desktop Standby UPS Unit
• پاور ڪنڊ
• استعمال ڪندڙ جو دستياب (ھي دستاويز)

If any items are missing or damaged, contact your vendor or Eaton support.

4. پراڊڪٽ ختمview

The Eaton 3S 550 VA UPS features multiple outlets for connecting your equipment, providing both battery backup and surge protection.

Image showing the front panel of the Eaton 3S 550 VA Desktop Standby UPS, typically featuring a power button and status indicators. The unit is black with a sleek design.

4.1 فرنٽ پينل

• پاور بٽڻ: يو پي ايس کي آن يا آف ڪرڻ لاءِ استعمال ڪيو ويندو آهي.
• حالت اشارو LED: Displays the operational status of the UPS (e.g., On-line, On-battery, Fault).

4.2 ريئر پينل

• AC ان پٽ: Connects the UPS to the wall outlet.
• Battery Backup Outlets (4 x NEMA 5-15R): Provide power from the battery during outages and surge protection. Connect critical equipment like computers, monitors, and external hard drives here.
• Surge Protection Only Outlets (4 x NEMA 5-15R): Provide surge protection only. Connect non-critical equipment like printers or scanners here.

5. سيٽ اپ

1. يو پي ايس کوليو: Carefully remove the UPS from its packaging. Inspect for any shipping damage.
2. Position the UPS: Place the UPS on a flat, stable surface in a well-ventilated area, away from direct sunlight, heat sources, and moisture. Ensure that the front and rear panels are accessible.
3. اي سي پاور سان ڳنڍيو: Plug the UPS power cord into a grounded wall outlet. The UPS will begin charging its internal battery. For optimal performance, allow the battery to charge for at least 8 hours before connecting equipment.
4. ڳنڍڻ جو سامان:
   • بيٽري بيڪ اپ آئوٽليٽس: Plug your critical equipment (e.g., computer, monitor, modem) into the outlets labeled "Battery Backup & Surge Protection."
   • صرف سرج پروٽيڪشن آئوٽليٽس: غير نازڪ سامان پلگ ان ڪريو (مثال طور، پرنٽر، ڊيسڪ lamp) into the outlets labeled "Surge Protection Only."
5. Turn On the UPS: Press and hold the power button on the front panel until the status indicator LED illuminates.

6. آپريٽنگ هدايتون

6.1 UPS کي آن/آف ڪرڻ

• چالو ڪرڻ لاء: Press and hold the power button until the status indicator LED lights up.
• بند ڪرڻ: Press and hold the power button until the status indicator LED turns off.

6.2 Status Indicators and Alarms

The UPS uses an LED indicator and audible alarms to communicate its status:

• مضبوط گرين LED: UPS is operating normally, providing AC power to connected equipment.
• Flashing Green LED & Audible Alarm: UPS is operating on battery power. This indicates a power outagاي يا سيوير وولtage fluctuation. The alarm will sound periodically.
• Rapid Flashing LED & Continuous Alarm: Indicates a low battery condition. The UPS will soon shut down to protect connected equipment.
• Other LED patterns/Alarms: Refer to the Troubleshooting section for specific fault indicators.

6.3 بيٽري رن ٽائم

The Eaton 3S 550 VA UPS provides approximately 0.05 hours (3 minutes) of runtime at full load (330W). Actual runtime will vary depending on the load connected and battery age. During a power outage, save your work and shut down your computer gracefully to prevent data loss.

7. سار سنڀال

7.1 بيٽري جي سنڀال

• شروعاتي چارج Ensure the UPS is charged for at least 8 hours before initial use.
• باقاعده استعمال: To maintain battery health, avoid storing the UPS with a completely discharged battery.
• بيٽري مٽائڻ: The internal battery is not user-replaceable. Contact Eaton support or a qualified service technician for battery replacement.
• بيٽري ڊسپوزل: مقامي ضابطن جي مطابق پراڻين بيٽرين کي ضايع ڪريو.

7.2 صفائي

يو پي ايس جي ٻاهرين حصي کي نرم، سڪل ڪپڙي سان صاف ڪريو. مائع يا ايروسول ڪلينر استعمال نه ڪريو. پڪ ڪريو ته وينٽيليشن جا سوراخ مٽي ۽ ملبي کان پاڪ آهن.

7.3 اسٽوريج

If storing the UPS for an extended period, ensure the battery is fully charged. Recharge the battery every 3-6 months to prevent permanent damage. Store in a cool, dry place.

8. مسئلا حل ڪرڻ

This section addresses common issues you might encounter with your Eaton 3S UPS.

If the problem persists after attempting these solutions, contact Eaton technical support.

9. وضاحتون

10. وارنٽي ۽ سپورٽ

For warranty information, please refer to the warranty card included with your product or visit the official Eaton website. For technical assistance, troubleshooting beyond this manual, or to inquire about service, please contact Eaton customer support.

Eaton Support: www.eaton.com/us/en-us/support.html

سپورٽ سان رابطو ڪرڻ وقت مھرباني ڪري پنھنجو ماڊل نمبر (8541618933) ۽ سيريل نمبر تيار رکو.
