تعارف
The TESmart 4x1 HDMI Switch HSW0401A1U allows you to connect up to four HDMI source devices to a single HDMI display. This device supports 4K@60Hz resolution, HDR, HDCP 2.2, and 3D, providing high-quality video and audio. It also features optical S/PDIF and L/R audio outputs for enhanced audio flexibility. Control is available via front panel buttons or an IR remote control, with an optional automatic switching mode for convenience.
شڪل 1: The TESmart 4x1 HDMI Switch streamlines connections, allowing multiple input devices to share a single display, reducing cable clutter.
اهم خاصيتون
- 4x1 HDMI Switcher: Connects up to four HDMI source devices to one HDMI display.
- 4K HDMI with Audio Output: Supports 3840x2160@60Hz 4:4:4, HDR, HDCP 2.2, and 1080P 3D. Includes S/PDIF optical and L/R analog audio outputs.
- گھڻا سوئچنگ طريقا: Easily switch between sources using front panel buttons, IR remote control, or automatic detection.
- وسيع مطابقت: Compatible with various HDMI sources such as PlayStation, Xbox, Nintendo Switch, Blu-ray players, set-top boxes, Chromecast, Apple TV, and projectors.
- پائيدار تعمير: ايلومينيم مصر جي خاصيت آهي جasing for enhanced durability.
شڪل 2: The switch supports advanced video technologies including 4K@60Hz, HDCP 2.2, HDR 10, and 3D for a high-quality viewتجربو.
شڪل 3: The switch offers broad compatibility with a range of input and output devices, making it versatile for different setups.
پيداوار ختمview
فرنٽ ۽ ريئر پينل
شڪل 4: Front and Rear Panel Layout of the TESmart 4x1 HDMI Switch.
فرنٽ پينل خاصيتون:
- IR وصول ڪندڙ: IR ريموٽ ڪنٽرول مان سگنل وصول ڪري ٿو.
- Input Selection Status LEDs (1-4): Indicate the currently active HDMI input.
- ان پٽ سليڪشن بٽڻ: Manually cycles through HDMI input sources.
- Audio Mode Selection Status LEDs (5.1, 2.0, Auto): Show the selected audio output mode.
- Audio Mode Selection Button: Toggles between 5.1 channel, 2.0 channel, and Auto audio output modes.
- پاور سوئچ: ڊوائيس کي آن يا بند ڪري ٿو.
ريئر پينل خاصيتون:
- ڊي سي 5V پاور ان پٽ: Connects to the provided 5V DC power adapter.
- HDMI Input Ports (1-4): پنهنجا HDMI سورس ڊوائيسز ڳنڍيو.
- HDMI Output Port: توھان جي HDMI ڊسپلي سان نيل آھي.
- S/PDIF Optical Audio Output: Connects to an optical audio receiver or soundbar.
- AUX L/R Audio Output: Connects to an analog audio system via a 3.5mm jack.
سيٽ اپ جون هدايتون
- HDMI ذريعن سان ڳنڍيو: Connect up to four HDMI source devices (e.g., gaming consoles, Blu-ray players, PCs) to the HDMI Input ports (1-4) on the rear panel of the switch using high-quality HDMI cables.
- HDMI ڊسپلي سان ڳنڍيو: Connect your HDMI display (TV, monitor, projector) to the HDMI Output port on the rear panel of the switch using a high-quality HDMI cable.
- آڊيو آئوٽ پُٽ ڳنڍيو (اختياري):
- For optical audio, connect an S/PDIF optical cable from the switch's S/PDIF port to your audio receiver or soundbar.
- For analog audio, connect a 3.5mm audio cable from the switch's L/R port to your audio system.
- پاور Connectنيو: Plug the provided 5V DC power adapter into the DC 5V input port on the switch, then plug the adapter into a power outlet.
- پاور آن: Turn on the HDMI switch using the power switch on the front panel. The LED indicators will illuminate.
آپريٽنگ هدايتون
Switching HDMI Inputs
شڪل 5: Multiple methods for switching between HDMI sources.
- Manual Switching (Front Panel): Press the "Input" button on the front panel to cycle sequentially through the connected HDMI sources (Input 1 → Input 2 → Input 3 → Input 4). The corresponding LED indicator will light up.
- IR ريموٽ ڪنٽرول: Use the provided IR remote control to directly select the desired input by pressing the corresponding number button (1, 2, 3, or 4). Ensure the remote is pointed towards the IR receiver on the front panel.
- خودڪار سوئچنگ: The switch supports automatic detection. When a new input device is attached or powered on, the HDMI switch will automatically switch to this newly plugged-in source. If a connected input source is removed, the HDMI switch will switch to the first valid input source automatically. If the HDMI switch is connected to a non-signal input port, it will switch to the next valid port automatically in a few seconds.
آڊيو موڊ جي چونڊ
- Press the "Audio" button on the front panel or the corresponding button on the IR remote to select the desired audio output mode: 5.1 channel, 2.0 channel, or Auto. This allows you to match the audio output to your sound system's capabilities.
وڊيو 1: This video demonstrates how to enable or disable the automatic detection switch mode on the TESmart 4x1 HDMI Switch, showing the button presses and LED indicator responses.
وضاحتون
| خاصيت | تفصيل |
|---|---|
| ماڊل نمبر | HSW0401A1U |
| پيداوار جي ماپ | 7.72 x 3.15 x 1.1 انچ |
| شيءِ جو وزن | 1.2 پائونڊ (500 گرام) |
| HDCP تعميل | 2.2 |
| ڊيٽا جي شرح | 18 جي بي پي ايس |
| وڌ ۾ وڌ ريڪارڊ | 3840x2160@60Hz 4:4:4 |
| آڊيو سپورٽ | Surround sound (up to 7.1ch) or stereo digital audio |
| ESD تحفظ | Human body model - ±8KV (Air-gap discharge) |
| ان پٽ | 4* HDMI قسم A |
| ٻاھر | 1* HDMI Type A, 1* AUX (for L/R audio out), 1* S/PDIF audio out |
| Chasinجي مواد | المونيم مصر |
| بجلي جي فراهمي | ڊي سي 5V 1A |
| آپريٽنگ / اسٽوريج گرمي پد | 0 to 70 degree / -40 to 85 degree Celsius |
| آپريٽنگ نمي | 10 کان 90٪ RH |
| ريموٽ بيٽري جو قسم | CR2025 (شامل نه آهي) |
مشڪلاتون
- ڪوبه سگنل يا چمڪندڙ ڊسپلي ناهي:
- پڪ ڪريو ته سڀئي HDMI ڪيبل محفوظ طور تي ڳنڍيل آهن.
- Use certified high-speed 18Gbps HDMI cables, especially for 4K@60Hz content, to prevent signal loss or flickering.
- Verify the correct input source is selected on the switch and your display.
- Try restarting the switch and connected devices.
- Audio Issues (No Sound or Incorrect Format):
- Check that your audio system is properly connected to the S/PDIF or L/R output ports.
- Ensure the audio mode on the switch (5.1, 2.0, Auto) matches the capabilities of your audio receiver or soundbar.
- Confirm that the audio settings on your source device are correctly configured for the desired output.
- IR Remote Control Not Responding:
- Ensure a CR2025 battery is correctly installed in the remote (battery not included).
- Point the remote directly at the IR receiver on the front panel of the switch.
- Remove any obstructions between the remote and the switch.
- ڊوائيس اوور گرم ڪرڻ:
- Ensure the switch is placed in a well-ventilated area and not covered, allowing for proper heat dissipation.
وارنٽي ۽ سپورٽ
The TESmart 4x1 HDMI Switch HSW0401A1U comes with a 1-year warranty from the date of order. Free technical support is available for any issues or questions you may have. For assistance, please contact TESmart support through the vendor's official channels.
