Browning Strike Force Extreme 16 MP Trail Camera User Manual

1. تعارف

This manual provides comprehensive instructions for the setup, operation, and maintenance of your Browning Strike Force Extreme 16 MP Trail Camera. Designed for high-performance outdoor monitoring, this camera captures high-quality images and videos with advanced features like rapid trigger speed and night vision capabilities. Please read this manual thoroughly to ensure optimal performance and longevity of your device.

2. مصنوعات جون خاصيتون

• 16 MP Images: Captures high-resolution still photographs.
• HD Videos with Sound: Records 1280 x 720 HD video clips with adjustable lengths (5 seconds to 2 minutes).
• Infrared LED Illumination: Provides clear night vision capabilities.
• 100 ft. Flash Range: Ensures wide illumination for night captures.
• Adjustable 80 ft. Detection Range: Customizable detection area for optimal monitoring.
• تيز ٽرگر اسپيڊ: Features an adjustable trigger speed of 0.4 – 0.7 seconds.
• جلدي بحالي جو وقت: Boasts a rapid 0.6-second recovery time between pictures.
• SDXC Memory Card Support: Compatible with up to 512GB SDXC memory cards (not included).
• بيٽري ميٽر: Functions with both Alkaline or Lithium batteries.
• ڪمپيڪٽ ڊيزائن: Measures 4.5" x 3.25" x 2.5" for discreet placement.
• Timelapse Plus Mode: Combines timelapse photography with IR triggered images.
• ڊگھي بيٽري زندگي: Operates efficiently on 6 AA batteries (not included).
• Multi Shot & Rapid Fire: Captures up to 8 multi-shot or rapid-fire images.
• ايس ڊي ڪارڊ انتظام: Offers options for managing storage space on the SD card.
• Smart IR Video: Continues recording video during the day when motion is detected.
• External Power Jack: Includes a 12-volt external power jack.
• رابطي: Equipped with TV Out and USB Port.
• Camo Finish: Blends seamlessly into outdoor environments.
• Picture Info Bar: Displays Time, Date, Temperature, Moon Phase, and Camera ID on images.
• Programmable Picture Delay: Adjustable delay from 1 second to 60 minutes.
• سافٽ ويئر مطابقت: Works with Browning Buck Watch Timelapse Viewer سافٽ ويئر.
• تپائي ساکٽ: Features a 1/4" -20 tripod socket for versatile mounting.

3. پيڪيج مواد

• Browning Strike Force Extreme 16 MP Trail Camera
• ڪئميرا پتي

4. سيٽ اپ

4.1 بيٽري لڳائڻ

Open the camera housing. Insert 6 AA batteries (not included) into the battery compartment, ensuring correct polarity as indicated inside the compartment.

Figure 4.1: Open camera showing battery compartment and controls.

4.2 ايس ڊي ڪارڊ داخل ڪرڻ

Insert an SDXC memory card (up to 512GB, not included) into the designated slot until it clicks into place. Ensure the card is inserted with the correct orientation.

4.3 پاور آن

Slide the power switch to the "ON" position. The camera will perform a self-test and the display will illuminate.

شڪل 4.2: سامهون view ڪئميرا جي.

4.4 شروعاتي سيٽنگون

Upon first power-on or after a battery change, use the control buttons (MODE, ENTER, and arrow keys) to set the current date, time, and other basic parameters as prompted on the display. Refer to the on-screen menu for navigation.

Figure 4.3: Browning Strike Force Extreme camera.

5. آپريٽنگ هدايتون

5.1 موڊ جي چونڊ

Use the "MODE" button on the control panel to cycle through the available operating modes: تصوير (for still images), وڊيو (for video recording), and Timelapse Plus (for time-lapse sequences with IR triggered images).

5.2 سيٽنگون ترتيب ڏيڻ

Navigate through the camera's menu using the arrow buttons. Press "ENTER" to select an option or confirm a setting. You can adjust parameters such as trigger speed, detection range, picture delay, video length, and more to suit your specific monitoring needs.

5.3 Smart IR Video

The Smart IR Video feature allows the camera to continue recording video as long as game is present during daylight hours, maximizing your capture opportunities.

5.4 SD ڪارڊ انتظام

Utilize the SD card management feature to either overwrite older files when the card is full (loop recording) or stop recording when the card reaches its capacity. This setting can be found in the camera's menu.

5.5 Picture Information Bar

Captured images will include an information bar displaying essential data such as Time, Date, Temperature, Moon Phase, and Camera ID. This helps in organizing and analyzing your captured media.

شڪل 5.1: مثالample night vision image captured by the camera.

شڪل 5.2: مثالample daytime image captured by the camera.

شڪل 5.3: ٻيو اڳوڻوample night vision image captured by the camera.

6. سار سنڀال

6.1 صفائي

Gently wipe the camera lens, IR LEDs, and housing with a soft, dry cloth to remove dirt, dust, or moisture. Avoid using abrasive cleaners or solvents, as they may damage the camera's finish or components.

6.2 بيٽري مٽائڻ

Replace batteries when the battery meter on the display indicates low power. Using fresh batteries ensures continuous operation and optimal performance, especially for night vision and video recording.

6.3 ايس ڊي ڪارڊ جي سنڀال

Periodically format your SD card (after backing up any important data) to maintain optimal performance and prevent data corruption. Store the camera in a cool, dry place when not in use, and ensure the battery compartment is securely closed to prevent moisture ingress.

7. مسئلا حل ڪرڻ

7.1 ڪئميرا آن نه ٿي رهيو آهي

• Check battery orientation and ensure batteries are fully charged or new.
• Ensure the power switch is fully in the "ON" position.
• Verify that the battery compartment is clean and free of corrosion.

7.2 خراب تصوير/وڊيو معيار

• Gently clean the camera lens and IR LEDs with a soft cloth.
• Ensure flash range and detection range settings are appropriate for the environment and subject distance.
• Check for obstructions in front of the lens or IR LEDs.

7.3 No Detection

• Adjust the detection range setting in the camera menu.
• Ensure the camera is positioned correctly, free from obstructions like branches or tall grass that might trigger false detections or block the sensor.
• Verify that the camera is not facing direct sunlight or strong heat sources, which can interfere with the PIR sensor.

7.4 SD Card Errors

• Reformat the SD card using the camera's menu option (this will erase all data).
• Try a different, high-quality SDXC memory card.
• پڪ ڪريو ته ڪارڊ مڪمل طور تي سلاٽ ۾ داخل ٿيل آهي.

8. وضاحتون

9. وارنٽي ۽ سپورٽ

This product is manufactured by Browning Trail Cameras. For customer service inquiries or technical support, please contact Browning Trail Cameras directly. You may reach them at (888) 618-4496. Refer to the product packaging or the official Browning Trail Cameras website for detailed warranty information and the most current support resources.
