تعارف
This manual provides instructions for the proper setup, operation, and maintenance of your Jasco Philips Broadcast TV Antenna, model SDV2227N/27. This antenna is designed to receive free local digital and HD broadcast television signals. It supports 1080p HD and 4K Ultra HD reception, with an effective range of up to 40 miles from the broadcast source. This passive antenna is compatible with all television brands. Please read this manual thoroughly before using the product.
Image of the Jasco Philips Broadcast TV Antenna SDV2227N/27, showing its compact design suitable for indoor use.
سيٽ اپ ڪريو
- اينٽينا کوليو: Carefully remove all components from the packaging. Ensure all parts are present.
- ٽي وي سان ڳنڍيو: Connect the coaxial cable from the antenna to the "Antenna In" or "Cable In" port on the back of your television.
- انٽينا جي پوزيشن: For optimal reception, place the antenna in a location with minimal obstructions, preferably near a window and facing the direction of local broadcast towers. You may need to experiment with different positions to find the best signal.
- Run a Channel Scan:
- پنهنجي ٽيليويزن کي موڙيو.
- Access your TV's setup menu (usually labeled "Menu," "Settings," or "Setup").
- Navigate to the "Channel Scan," "Auto Program," or "Auto Tune" option.
- Select "Antenna" or "Air" as the input source, then initiate the scan. This process may take several minutes.
- Adjust for Best Signal: After the scan, check the picture quality of the received channels. If reception is poor on certain channels, try repositioning the antenna and running another channel scan.
آپريٽنگ
Once the antenna is set up and a channel scan is complete, operating the antenna is straightforward.
- چينل چونڊ: Use your television's remote control to change channels as you normally would.
- سگنل جي طاقت: Some televisions have a signal strength meter in their settings menu. This can be useful for fine-tuning antenna placement.
- Rescanning Channels: It is recommended to rescan for channels periodically (e.g., monthly) or if you notice a loss of channels, as broadcast towers may change frequencies or new channels may become available.
سار سنڀال
The Jasco Philips Broadcast TV Antenna requires minimal maintenance.
- صفائي: Dust the antenna periodically with a soft, dry cloth. Do not use liquid cleaners or abrasive materials.
- ڪيبل جي چڪاس: Periodically check the coaxial cable for any signs of damage or wear. Ensure connections are secure.
- صرف اندروني استعمال: This antenna is designed for indoor use. Do not expose it to outdoor elements, extreme temperatures, or moisture.
مشڪلاتون
| مسئلو | ممڪن سبب | حل |
|---|---|---|
| No channels found or poor reception. |
|
|
| Picture freezes or pixelates. |
|
|
| Some channels are missing. |
|
|
وضاحتون
- ماڊل: SDV2227N/27
- برانڊ: جسڪو
- Antenna جو قسم: Passive, Indoor
- استقبال: Digital, HD, 4K Ultra HD
- حد: Up to 40 miles (from broadcast source)
- مطابقت: All television brands
- شيء جو وزن: 13.8 اونس
- UPC: 030878409988
- ASIN: B08CT2MYY2
وارنٽي ۽ سپورٽ
For warranty information or technical support, please refer to the contact information provided with your product packaging or visit the official Jasco webسائيٽ. وارنٽي جي دعوي لاء توهان جي خريداري جي رسيد رکو.
Jasco پراڊڪٽس ڪمپني LLC
