1. تعارف
The POOLEX Poolstar Nano Action 4 is a compact and efficient heat pump designed specifically for above-ground swimming pools. This manual provides essential information for the safe and effective installation, operation, and maintenance of your heat pump, ensuring you can extend your swimming season and enjoy comfortable water temperatures.
تصوير 1.1: سامهون view of the POOLEX Poolstar Nano Action 4 Heat Pump.
2. حفاظت جي ڄاڻ
مھرباني ڪري انسٽاليشن ۽ آپريشن کان اڳ سڀ حفاظتي هدايتون احتياط سان پڙھو. انھن هدايتن تي عمل ڪرڻ ۾ ناڪامي بجليءَ جو جھٽڪو، باهه، يا سنگين زخمي ٿي سگھي ٿي.
- Ensure the power supply matches the specifications of the heat pump.
- Do not operate the heat pump if the power cable or plug is damaged.
- آپريشن دوران ٻارن ۽ پالتو جانورن کي يونٽ کان پري رکو.
- The 5-meter power cable is equipped with a 10 mA differential protection for enhanced safety. Do not bypass or modify this safety feature.
- ڪنهن به سار سنڀال يا صفائي ڪرڻ کان اڳ هميشه بجلي بند ڪريو.
- يونٽ جي چوڌاري مناسب وينٽيليشن کي يقيني بڻايو. هوا جي داخل ٿيڻ يا آئوٽليٽ کي بلاڪ نه ڪريو.
3. پيڪيج مواد
Verify that all items are present in the packaging before beginning installation.
- POOLEX Poolstar Nano Action 4 Heat Pump unit
- Power cable with 10 mA differential protection (5 meters)
- PVC connections (32 mm diameter, 1.5 inch)
- سار سنڀال کٽ
- گھڻ لساني استعمال ڪندڙ دستي
Image 3.1: The POOLEX Poolstar Nano Action 4 heat pump packaging, showing included accessories.
4. سيٽ اپ ۽ تنصيب
The Nano Action 4 heat pump features a "Plug & Play" design for quick and easy installation. No bypass is required for its operation.
4.1. رکڻ
Place the heat pump on a stable, level surface near your above-ground pool. Ensure there is adequate space around the unit for proper airflow (at least 50 cm clearance on all sides, especially around the fan and air vents).
4.2. پاڻي جا ڪنيڪشن
- Connect the pool's filtration system outlet to the "IN" port of the heat pump using the provided 32 mm PVC connections.
- Connect the "OUT" port of the heat pump back to the pool's inlet.
- پڪ ڪريو ته سڀئي ڪنيڪشن محفوظ ۽ پاڻي کان محفوظ آهن ته جيئن ليڪ کي روڪي سگهجي.
Image 4.1: Included PVC connections (32mm diameter) for connecting to your pool's filtration system.
4.3. بجليءَ وارا ڪنيڪشن
- Plug the 5-meter power cable into a standard electrical outlet. The cable includes a 10 mA differential protection for safety.
- Do not use extension cords or adapters unless absolutely necessary and ensure they are rated for outdoor use and the heat pump's power requirements.
Image 4.2: The 5-meter power cable with integrated 10 mA differential protection for safe operation.
تصوير 4.3: اڳوڻيample setup of the POOLEX Nano Action 4 heat pump connected to an above-ground pool.
5. آپريٽنگ هدايتون
The POOLEX Poolstar Nano Action 4 is designed for ease of use, allowing you to quickly heat your pool water.
5.1. شروعاتي شروعات
Once connected, ensure your pool's filtration system is running. The heat pump will begin to operate automatically when the water flow is detected and the temperature setting requires heating. The unit is capable of operating effectively from an ambient temperature of 8°C.
5.2. درجه حرارت ڪنٽرول
Use the control panel on the unit to set your desired water temperature. The heat pump will work to achieve and maintain this temperature, significantly extending your bathing season.
5.3. Extending the Bathing Season
This heat pump is ideal for wooden or steel pools and can heat your pool in just a few hours, allowing you to enjoy your pool earlier in the spring and later into the autumn.
6. سار سنڀال
Regular maintenance ensures the longevity and efficient operation of your heat pump.
- صفائي: وقتي طور تي يونٽ جي ٻاهرين حصي کي نرم، ڊي سان صاف ڪريوamp cloth. Ensure the air intake and exhaust grilles are free from debris, leaves, and other obstructions.
- پاڻي جي معيار: Maintain proper pool water chemistry to prevent scale buildup and corrosion within the heat pump.
- سياري ڪرڻ: If you live in an area with freezing temperatures, follow proper winterization procedures to drain the unit and protect it from frost damage. Consult the detailed multilingual manual for specific steps.
- Maintenance Kit: Utilize the provided maintenance kit for routine care as instructed in the full manual.
7. مسئلا حل ڪرڻ
هي حصو عام مسئلن کي حل ڪري ٿو جيڪي توهان کي درپيش اچي سگهن ٿا. وڌيڪ پيچيده مسئلن لاءِ، مهرباني ڪري ڪسٽمر سپورٽ سان رابطو ڪريو.
| مسئلو | ممڪن سبب | حل |
|---|---|---|
| گرمي پمپ آن نه ٿي رهيو آهي. | No power, tripped breaker, insufficient water flow. | Check power connection, reset breaker, ensure pool pump is running and water flow is adequate. |
| ناکافي گرمي. | Low ambient temperature, dirty coils, incorrect temperature setting, pool too large. | Verify temperature setting, clean coils, ensure unit is suitable for pool volume. Note that performance decreases in very low temperatures. |
| Error Code P7 (Frost Protection). | Unit detects freezing conditions or a sensor malfunction. | Ensure ambient temperature is above 8°C. If the temperature is warm and the error persists, contact customer support. |
| غير معمولي شور. | Debris in fan, loose components. | Inspect fan for obstructions. If noise persists, contact customer support. |
8. وضاحتون
| خاصيت | تفصيل |
|---|---|
| ماڊل نمبر | PC-NANO-A4 |
| ٺاهيندڙ | پول اسٽار |
| پيداوار جي ماپ (L x W x H) | 40 x 28 x 38.5 سينٽي |
| وزن | 20 ڪلو |
| بجلي جو استعمال | 810 ڊبليو |
| تجويز ڪيل پول حجم | 15 کان 28 م³ |
| گھٽ ۾ گھٽ آپريٽنگ گرمي پد | 8 °C |
| برقي تحفظ | 10 mA differential protection |
| نلي ڪنيڪشن | 32 mm diameter, 1.5 inch |
9. وارنٽي ۽ سپورٽ
All POOLEX products come with a comprehensive warranty to ensure your peace of mind.
9.1. پراڊڪٽ وارنٽي
The POOLEX Poolstar Nano Action 4 heat pump is covered by a 2 سال وارنٽي from the date of purchase. Please retain your proof of purchase and warranty documentation for any claims.
9.2. ڪسٽمر سپورٽ
For technical assistance, troubleshooting beyond this manual, or warranty claims, please contact Poolstar customer service. Having your model number (PC-NANO-A4) and purchase details ready will help expedite your request.
For more information, you can visit the official Poolstar website or the POOLEX Store on Amazon: POOLEX Store
