وي سي ايم موبائل ليڪٽرن لاڪ ڪرڻ لائق دراز ۽ ڦيٿين سان (بلوط اڇو/هني) استعمال ڪندڙ دستي

1. تعارف

Thank you for choosing the VCM Mobile Lectern. This product is designed to provide a versatile and mobile workstation or presentation stand. Featuring a height-adjustable top plate, a lockable drawer, and smooth-rolling wheels, it offers convenience and functionality for various environments. This manual contains essential information for the correct assembly, safe operation, and proper maintenance of your new lectern.

Image 1.1: The VCM Mobile Lectern with its top plate angled and the lockable drawer partially open, showcasing ان جي ڊيزائن ۽ خاصيتون.

2. حفاظت جي ڄاڻ

• اسيمبليءَ ۽ استعمال کان اڳ سڀ هدايتون احتياط سان پڙهو.
• ننڍن حصن ۽ پيڪنگنگ مواد کي ٻارن کان پري رکو ته جيئن ٿڪڻ جي خطرن کي روڪيو وڃي.
• Ensure all screws and fasteners are tightened securely during assembly. Periodically check for tightness.
• Do not overload the lectern or drawer. Refer to specifications for weight limits.
• Use the wheel brakes to stabilize the lectern when it is in a stationary position.
• گرم شيون سڌو سنئون مٿاڇري تي بغير حفاظت جي رکڻ کان پاسو ڪريو.
• Do not stand or climb on the lectern.

3. پيڪيج مواد

اسيمبلي شروع ڪرڻ کان اڳ، پڪ ڪريو ته سڀئي جزا موجود آهن ۽ انهن کي ڪو نقصان نه پهتو آهي. پيڪيج ۾ شامل هجڻ گهرجي:

• VCM Mobile Lectern components (wooden panels, hardware)
• Assembly materials (screws, dowels, cam locks, etc.)
• Simple assembly instructions
• Key for the lockable drawer

If any parts are missing or damaged, please contact VCM customer support immediately.

4. سيٽ اپ ۽ اسيمبلي جون هدايتون

Assembly of the VCM Mobile Lectern requires careful attention. Follow the included assembly instructions step-by-step. It is recommended to assemble the unit on a soft, clean surface to prevent scratches.

4.1 جنرل اسيمبلي جون صلاحون

• Identify all parts before starting.
• Use the correct hardware for each step as indicated in the instructions.
• Do not overtighten screws, as this can damage the wood.
• Some users have reported that pre-drilled holes may not always be clearly marked; verify positions before drilling if necessary.

4.2 Wheel Installation

When installing the four wheels, ensure they are correctly oriented. It is recommended to place the two wheels with brakes on either the front or back side for optimal stability and ease of locking. Securely fasten all wheels to the base of the lectern.

Image 4.1: Technical line drawing illustrating the dimensions of the VCM Mobile Lectern, including its height-adjustable top plate and overall structure.

5. آپريٽنگ هدايتون

5.1 Adjusting the Top Plate Height

The top plate of the lectern is designed to be height-adjustable. To adjust the height, locate the securing mechanism (e.g., screws or a plastic cap) beneath the top plate. Loosen this mechanism, set the plate to your desired height between approximately 108 cm and 120 cm, and then firmly re-secure the mechanism to prevent movement. Ensure the plate is stable before placing items on it.

5.2 Using the Lockable Drawer

The lectern features a lockable drawer for secure storage of documents, pens, or other small items. Insert the provided key into the lock and turn to secure or unlock the drawer. Always ensure the drawer is fully closed before moving the lectern.

Image 5.1: The VCM Mobile Lectern with its lockable drawer fully extended, demonstrating the internal storage capacity.

5.3 متحرڪ ۽ استحڪام

The four integrated wheels allow for easy movement of the lectern. To move, simply unlock the wheel brakes (if engaged) and push the lectern to the desired location. Once positioned, engage the wheel brakes to prevent unintended movement and ensure stability during use.

تصوير 5.2: هڪ پاسي view of the VCM Mobile Lectern, highlighting the design and the mobility provided by its wheels.

6. سار سنڀال

• صفائي: مٿاڇري کي نرم سان صاف ڪريو، ڊيamp ڪپڙو. گھڙڻ وارا صاف ڪندڙ يا سخت ڪيميڪلز کان پاسو ڪريو جيڪي ختم کي نقصان پهچائي سگھن ٿا.
• هارڊويئر: وقت بوقت سڀني اسڪرو ۽ فاسٽنرز کي چيڪ ڪريو ته جيئن پڪ ڪري سگهجي ته اهي تنگ رهن. جيڪڏهن ضروري هجي ته ٻيهر مضبوط ڪريو.
• ڦيٿي: Keep the wheels free of debris to ensure smooth movement. If a wheel becomes damaged, contact customer support for replacement options.
• تالا: Apply a small amount of graphite lubricant to the drawer lock if it becomes stiff.

7. مسئلا حل ڪرڻ

• اسيمبلي ۾ مشڪلات: Refer to the included assembly instructions carefully. If pre-drilled holes are unclear, verify placement before proceeding. Contact customer support if parts are missing or damaged.
• Wheels Detaching or Breaking: Ensure wheels are securely attached during assembly. Avoid excessive force when moving the lectern, especially over uneven surfaces. Replacement wheels may be available from the manufacturer.
• Top Plate Not Adjusting: Some models may have a securing cap or screw that needs to be loosened before height adjustment. Ensure it is fully disengaged before attempting to change height.
• Drawer Not Locking Smoothly: Check for any obstructions in the drawer mechanism. Ensure the key is fully inserted and turned correctly.

8. وضاحتون

9. وارنٽي ۽ سپورٽ

VCM products are manufactured to high-quality standards. For information regarding warranty coverage, please refer to the warranty card included with your product or visit the official VCM website. For technical support, replacement parts, or any other inquiries, please contact VCM customer service through the contact information provided on the VCM webسائيٽ يا توهان جي خريداري دستاويز.
