1. پراڊڪٽ ختمview
The HCALORY 8KW Diesel Heater (Model HBU1S) is a versatile air heating solution designed for various applications including RVs, garages, and cabins. It features rapid warm-up capabilities, high combustion efficiency, and multiple control options including a user-friendly Bluetooth app, remote control, and an integrated control panel. Advanced safety features and high-altitude operational modes ensure reliable performance in diverse environments.
Image 1.1: HCALORY 8KW Diesel Heater unit with included remote control and LCD control panel.
2. حفاظت جي ڄاڻ
خبردار: غلط تنصيب، ترتيب، ڦيرڦار، خدمت، يا سار سنڀال ملڪيت کي نقصان، زخم، يا موت جو سبب بڻائيندو. هن سامان کي نصب ڪرڻ يا خدمت ڪرڻ کان پهريان انسٽاليشن، آپريٽنگ، ۽ سار سنڀال جي هدايتن کي چڱي طرح پڙهو.
- ڪاربن مونو آڪسائيڊ جو خطرو: This heater produces carbon monoxide, which is odorless and can be deadly. Always ensure proper ventilation and exhaust routing to the outside. Never operate the heater in an enclosed space without adequate ventilation.
- ٻارڻ سنڀالڻ: Use only diesel fuel. Do not use gasoline or other volatile fuels. Ensure fuel lines are securely connected and free from leaks.
- گرم سطحون: The heater unit and exhaust components become extremely hot during operation. Avoid contact with hot surfaces to prevent burns. Keep flammable materials away from the heater.
- وينٽيليشن: Ensure the intake and exhaust pipes are clear of obstructions and properly routed to the outside atmosphere. The combustion air intake must draw fresh air from outside the heated space.
- برقي ڪنيڪشن: Connect the heater to a 12V or 24V power source as specified. Ensure all electrical connections are secure and properly insulated to prevent short circuits.
- تنصيب: Install the heater on a stable, non-flammable surface. Follow all local codes and regulations for installation.
- هنگامي بندش: Familiarize yourself with the emergency shutdown procedure. Do not unplug the unit directly during operation; allow it to complete its cool-down cycle.
3. سيٽ اپ ۽ تنصيب
The HCALORY Diesel Heater is designed for flexible installation in various scenarios. Proper setup is crucial for safe and efficient operation.
3.1 انباڪسنگ ۽ جزو جي سڃاڻپ
Upon receiving your heater, carefully unbox all components and verify against the packing list. The kit typically includes the main heater unit, fuel tank, exhaust pipe, intake pipe, muffler, fuel pump, fuel lines, wiring harness, control panel, remote control, and various mounting accessories.
Video 3.1: Unboxing and initial setup of the diesel heater components.
3.2 Mounting the Heater
The heater can be installed in either a vertical or horizontal position. Use the provided mounting plate and hardware to secure the unit to a stable surface. Ensure sufficient clearance around the unit for proper airflow and maintenance.
تصوير 3.2: اڳوڻيamples of flexible installation locations for the HCALORY Diesel Heater.
3.3 Exhaust and Intake System
Connect the exhaust pipe and intake pipe to the designated ports on the bottom of the heater. Route both pipes to the outside of the heated space, ensuring they are securely fastened and free from kinks or obstructions. The exhaust pipe should have a slight downward slope to allow for condensation drainage. The intake pipe should draw fresh air from outside.
Video 3.3: 3D model demonstrating the installation of the exhaust and intake pipes.
3.4 Fuel System Connection
Connect the fuel lines from the fuel tank to the fuel pump, and then from the fuel pump to the heater unit. Ensure all connections are tight and leak-free. The fuel pump should be installed at a 45-degree angle to prevent air bubbles. The 10L fuel tank provides ample capacity for extended operation.
Video 3.4: Detailed instructions for connecting the diesel fuel system.
3.5 برقي ڪنيڪشن
Connect the wiring harness to the heater and to your 12V/24V power source. Ensure correct polarity (red to positive, black to negative). The control panel connects via an extension cable, allowing flexible placement within your space.
4. آپريٽنگ هدايتون
The HCALORY Diesel Heater offers multiple ways to control its operation, providing convenience and flexibility.
4.1 ڪنٽرول پينل آپريشن
The integrated LCD control panel allows direct control over the heater's functions. You can power on/off, adjust heat levels (1-10), set timers, and monitor operational data.
Video 4.1: Tutorial on how to use the heater's control panel.
4.2 بلوٽوٿ ايپ ڪنٽرول
Download the HCALORY app to control your heater from your smartphone within a 32 ft range. The app allows you to set up to 3 separate timers, adjust heat levels, and activate automatic start-stop functions.
تصوير 4.2: مٿيview of the three control methods for the heater.
4.3 ريموٽ ڪنٽرول
An optional remote control provides convenient operation from a distance of up to 98 ft.
4.4 Starting and Stopping the Heater
- شروع ٿيندڙ: Press and hold the power button on the control panel or use the app/remote. The unit will initiate a startup sequence, including fuel priming and fan activation.
- روڪڻ: Press and hold the power button until the display indicates shutdown. The heater will enter a cool-down cycle, during which the fan continues to run to prevent overheating. Do not disconnect power until the cool-down cycle is complete.
4.5 Altitude Mode
For optimal performance at higher altitudes, manually select the appropriate altitude mode (8202 ft or 16400 ft) via the control panel or app. This adjusts the air-fuel ratio for efficient combustion in thinner air.
Image 4.3: Smart Dual-Altitude Mode ensures efficient operation at different elevations.
5. سار سنڀال
Regular maintenance ensures the longevity and efficient operation of your HCALORY Diesel Heater.
5.1 Carbon Cleaning
If the machine develops carbon deposits, use the carbon cleaning function available through the control panel. Power on the machine using the designated switch and let it run for 30 to 60 minutes. This process helps burn off internal carbon deposits.
Video 5.1: Control panel function tutorial, including carbon cleaning.
5.2 عام صفائي ۽ چڪاس
- Regularly inspect the intake and exhaust pipes for any blockages or damage.
- Check fuel lines for leaks or cracks.
- Keep the exterior of the heater clean and free from dust and debris.
6. مسئلا حل ڪرڻ
The control panel provides error alerts and troubleshooting guidance for common issues.
- سينسر جي غلطي: If a sensor malfunctions, the display will show a 'Sensor Error' alert. Check if the temperature sensor is in poor contact with the motherboard connector or if it is damaged. Replace if necessary.
- گھٽ تيل: The system will alert you when the fuel level is low. Refill the fuel tank promptly.
- Motor Alarm: If the motor triggers an alarm, the system will guide you through troubleshooting steps on the display.
Video 6.1: Control panel tutorial showing error alerts and troubleshooting guidance.
7. وضاحتون
- برانڊ: ايڇ ڪيلوري
- ماڊل: HBU1S (SKUK63123)
- حرارتي طاقت: 8 ڪلوواٽ
- ٻارڻ جي ٽانڪي گنجائش: 10 ايل
- جلدtage: 12V/24V (compatible)
- شيء جو وزن: 15.62 پائونڊ
- پيڪيج جي ماپ: 18.4 x 17.6 x 10.2 انچ
- ڪنٽرول طريقا: Bluetooth App, Remote Control, LCD Control Panel
- خاص خاصيتون: High-Altitude Mode, Automatic Start/Stop, Multiple Timed Settings
8. وارنٽي ۽ سپورٽ
For warranty information and customer support, please refer to the documentation provided with your purchase or contact HCALORY customer service directly. Keep your proof of purchase for warranty claims.
