AOBOCAM Mini WiFi Camera User Manual

1. تعارف

Thank you for choosing the AOBOCAM Mini WiFi Camera. This compact and versatile camera is designed for home security and surveillance, offering 1080P HD video, night vision, motion detection, and dual connectivity via WiFi and Bluetooth. This manual provides detailed instructions to help you set up, operate, and maintain your camera for optimal performance.

2. حفاظت جي ڄاڻ

• استعمال ڪرڻ کان پهريان سڀ هدايتون احتياط سان پڙهو.
• Keep the camera away from water and moisture.
• Do not expose the camera to extreme temperatures or direct sunlight.
• چارج ڪرڻ وقت مناسب وينٽيليشن کي يقيني بڻايو وڃي ته جيئن وڌيڪ گرم ٿيڻ کان بچي سگهجي.
• صرف مهيا ڪيل چارجنگ ڪيبل يا تصديق ٿيل برابر استعمال ڪريو.
• Do not attempt to disassemble or repair the camera yourself. Contact customer support if issues arise.

3. پيڪيج مواد

• 1 x AOBOCAM Mini WiFi Camera (Model A12)
• 1 x USB چارجنگ ڪيبل
• 1 x استعمال ڪندڙ دستياب
• Note: An SD card (8-256GB) is required for local storage and is not included.

4. پراڊڪٽ ختمview

The AOBOCAM A12 is a compact and discreet camera designed for versatile placement. Its small size and magnetic properties allow it to be easily hidden or mounted in various locations.

Image: The AOBOCAM Mini WiFi Camera, showcasing its compact design and a smartphone displaying its live monitoring capabilities with WiFi and Bluetooth indicators.

تصوير: تفصيلي view of the AOBOCAM Mini WiFi Camera, highlighting its approximate dimensions (1.5in x 1.5in x 0.7in) and key features such as 1080P HD, magnetic mounting, motion detection, and mini DV functionality.

تصوير: Examples of the AOBOCAM Mini WiFi Camera's magnetic mounting capabilities, showing it placed on a ceiling, a metal pipe, a wooden table, and discreetly in various indoor settings.

5. سيٽ اپ گائيڊ

5.1 شروعاتي چارجنگ

Before first use, it is highly recommended to charge the camera for at least 1 hour to ensure optimal battery performance. Connect the camera to a power source using the provided USB cable. Place the camera in a well-ventilated area during charging to prevent overheating.

5.2 ايپ جي انسٽاليشن

ڊائون لوڊ ۽ انسٽال ڪريو HIDVCAM application on your smartphone. The app is available for both iOS and Android devices.

5.3 وائي فائي ۽ بلوٽوٿ سان ڳنڍڻ

The AOBOCAM A12 camera offers dual WiFi and Bluetooth connectivity for easier and faster pairing. The connection process typically takes around 10 seconds.

1. قدم 1: ڪئميرا تي پاور.
2. قدم 2: Open the HIDVCAM application on your smartphone.
3. قدم 3: Tap the "+" icon within the app to add a new device.
4. قدم 4: The camera's Bluetooth name (e.g., HWIPC-XXXXXX) will appear. Tap "Add" to proceed.
5. قدم 5: Select your WiFi router from the list, enter your WiFi password, and then tap "Next" followed by "Confirm." Ensure your phone is already connected to the same WiFi network before this step.

Image: A visual guide illustrating the three steps for Bluetooth connection: logging into the app, powering on the camera, and adding the device via Bluetooth to connect to WiFi.

Image: The AOBOCAM camera demonstrating its dual WiFi and Bluetooth connectivity, showing a user monitoring their cats via the smartphone app.

Note: This camera only supports 2.4GHz WiFi networks. Most modern routers are dual-band (2.4GHz/5GHz), so ensure you connect to the 2.4GHz band.

5.4 SD ڪارڊ لڳائڻ

The camera supports local storage via an SD card (not included) ranging from 8GB to 256GB. Insert the SD card into the designated slot on the camera. The camera features loop recording, which automatically overwrites the oldest footage when the card is full, ensuring continuous video coverage.

Image: Illustration of storage options, showing the camera with an SD card slot and an icon representing cloud storage, indicating both local and optional cloud storage capabilities.

6. آپريٽنگ هدايتون

6.1 وڊيو رڪارڊنگ

The AOBOCAM A12 records video in 1080P HD resolution, equipped with high-quality lenses and image sensors for stable and excellent image quality. It features a 120° ultra-wide-angle HD lens, capturing a broad field of view.

6.2 رات جو خواب

The camera is equipped with infrared (IR) LEDs, enabling it to capture clear images even in low-light conditions or complete darkness. This ensures continuous monitoring day and night.

Image: A comparison demonstrating the superior clarity of the AOBOCAM camera's night vision (labeled 'Nuestro') compared to other cameras (labeled 'Otros'), showing a cat in low light.

Image: A split image showing the difference between a clear 1080P daytime image and an equally clear HD night vision image of a sleeping baby, highlighting the camera's performance in varying light conditions.

6.3 حرڪت جي ڳولا جا الرٽ

The A12 camera's motion detection function identifies changes in a scene by comparing differences between consecutive frames. When motion is detected, the camera activates an alert or begins recording, sending a notification to your smartphone as quickly as possible. This feature enhances surveillance efficiency by ensuring you are promptly informed of critical events.

Image: A scenario depicting a motion detection alert from the AOBOCAM camera appearing on a smartphone, indicating a potential security event.

Image: A smartphone displaying a motion detection notification from the HIDVCAM app, with a family entering a home in the background, illustrating how the camera captures and alerts users to movement.

6.4 24/7 Monitoring

The A12 camera supports 24/7 surveillance. It has a built-in battery for portable use, or it can be connected directly to a power source for continuous operation, ensuring uninterrupted security monitoring day and night.

6.5 Cloud Storage (Optional)

In addition to SD card storage, the camera supports optional cloud storage (subscription required). This provides an alternative for storing your video footage securely off-site.

7. سار سنڀال

• صفائي: ڪئميرا لينس ۽ باڊي صاف ڪرڻ لاءِ نرم، سڪل ڪپڙو استعمال ڪريو. مائع صاف ڪندڙ يا ايروسول استعمال نه ڪريو.
• اسٽوريج: When not in use for extended periods, store the camera in a cool, dry place.
• بيٽري جي سنڀال: بيٽري جي زندگي کي وڌائڻ لاءِ، بيٽري کي بار بار مڪمل طور تي چارج ڪرڻ کان پاسو ڪريو. ان کي باقاعدي طور تي چارج ڪريو، جيتوڻيڪ مسلسل استعمال ۾ نه هجي.

8. مسئلا حل ڪرڻ

• ڪئميرا آن نه آهي: Ensure the camera is fully charged. Connect it to a power source and wait for the charging indicator.
• وائي فائي سان ڳنڍي نٿو سگهي:
  • Verify your WiFi network is 2.4GHz. The camera does not support 5GHz.
  • Ensure your phone is connected to the same 2.4GHz WiFi network during setup.
  • Check your WiFi password for accuracy.
  • پنهنجو روٽر ۽ ڪئميرا ٻيهر شروع ڪريو، پوءِ ٻيهر ڳنڍڻ جي ڪوشش ڪريو.
• خراب تصوير جي معيار:
  • ڪئميرا لينس کي نرم ڪپڙي سان صاف ڪريو.
  • Ensure adequate lighting in the monitoring area, especially for daytime recording.
  • Check your internet connection speed if streaming live video.
• حرڪت جي ڳولا ڪم نه ڪري رهي آهي:
  • Ensure motion detection is enabled in the HIDVCAM app settings.
  • Adjust motion sensitivity settings in the app.
  • ڪئميرا جي فيلڊ ۾ رڪاوٽن جي جانچ ڪريو view.
• Camera overheating during charging: This is a protective measure. Ensure the camera is placed in a well-ventilated area. If it continues to overheat and shut down, contact customer support.

9. وضاحتون

10. وارنٽي ۽ سپورٽ

For any questions, technical support, or warranty inquiries regarding your AOBOCAM Mini WiFi Camera, please contact AOBOCAM customer service through the retailer's platform or the contact information provided with your purchase. Please have your model number (A12/ESA12) and purchase details ready when contacting support.
