PURELINE PL-5700

Pureline PL-5700 Replacement Refrigerator Water Filter

For Bosch Ultra Clarity Pro Refrigerators

پيداوار ختمview

The Pureline PL-5700 refrigerator water filter is designed as an ideal replacement for Bosch Ultra Clarity Pro water filters. It features an advanced highly activated carbon block core to effectively reduce chlorine, sediment, rust, volatile organic compounds (VOCs), particles, bad taste, and other impurities from your tap water, providing clean and fresh-tasting water.

This filter is independently certified by IAPMO for NSF-42 for comprehensive reduction of chlorine and impurities, as well as NSF-372 for material safety, ensuring quality and safety.

Pureline water filter with icons for no tools needed, leak-free system, perfect fit, natural carbon, and triple action filter.

Image: Pureline water filter highlighting key features like easy installation and effective filtration.

سيٽ اپ ۽ تنصيب

The Pureline PL-5700 filter is designed for a perfect fit and is fully compatible with your Bosch refrigerator. Installation is straightforward and requires no special tools.

تنصيب جا مرحلا:

  1. Locate the existing water filter in your refrigerator.
  2. Turn the old filter 90 degrees counter-clockwise to unlock it, then pull it out to remove. A small amount of water may drip, so have a cloth ready.
  3. Insert the new Pureline PL-5700 filter into the filter opening.
  4. Turn the new filter 90 degrees clockwise until it locks securely into place.
  5. Flush approximately 3-4 gallons (15-19 liters) of water through the dispenser to purge air and carbon fines from the system. Discard the first few batches of ice produced.

Important: To reduce the risk of property damage due to water leakage, you must read and follow the installation and user instructions before installing the filter. The filter must be changed at least every 6 months.

Pureline water filter with text 'Easy to Install' and icons for no tools needed, perfect fit, and leak-free system.

Image: Visual guide illustrating the ease of installation with no tools required.

Video: A user demonstrates the simple installation of a compatible water filter in a Bosch refrigerator, highlighting the ease of replacement.

آپريٽنگ اصول

The Pureline PL-5700 filter utilizes a multi-stage filtration process to purify your water. Water passes through an activated carbon block made from food-grade coconut shell material, which effectively captures and reduces various contaminants.

  • Tri-Layer Filtration: Designed to efficiently remove impurities.
  • چالو ڪاربن فلٽر: Raw organic carbon effectively reduces impurities.
  • 2 Micron Filter Pore Size: High-efficiency filter strains even small particles.
Diagram showing tri-layer filtration removing particles, debris, odor, and rust.

Image: An illustration of the filter's tri-layer filtration system, demonstrating how it removes various impurities.

Diagram showing water flowing through an activated carbon filter, illustrating 2 micron pore size and clean purified water output.

تصوير: تفصيلي view of the filter's internal structure, highlighting the activated carbon and 2-micron pore size for effective purification.

Video: This video illustrates the filtration capabilities, showing how the filter reduces chlorine and other impurities to provide clean water.

سار سنڀال

For optimal performance and water quality, it is recommended to replace your Pureline PL-5700 water filter every 6 مهينا يا فلٽر ڪرڻ کان پوءِ 300 گيلن of water, whichever comes first. Regular replacement ensures consistent water purity and taste.

Image showing a couple with a water filter and icons indicating 300 gallons and 6 months for filter life.

Image: Highlights the filter's lifespan, indicating it provides 300 gallons or 6 months of fresh water.

مشڪلاتون

If you experience issues such as slow water flow or unusual taste after installing a new filter, ensure the filter is correctly seated and locked. It is crucial to flush the recommended amount of water (3-4 gallons) through the dispenser after installation to remove any trapped air or carbon particles. If problems persist, refer to your refrigerator's user manual or contact customer support.

وضاحتون

ماڊل نمبرPL-5700
موادActivated Coconut Charcoal
پيداوار جي ماپ2"ڊي x 2"ڊي x 8"ايڇ
شيءِ جو وزن0.26 ڪلوگرام (9.1 اونس)
خارجي جاچ جي سرٽيفڪيشنIAPMO, NSF (NSF-42, NSF-372)
پيداوار جا فائداReduces Chlorine, Sediment, Rust, VOCs, Particles, Bad Taste, Odor
فلٽر زندگي6 مهينا يا 300 گيلن
لاءِ مطابقت رکندڙ متبادلUltraClarity Pro, BORPLFTR50, BORPLFTR55, 11025825, B36CT80SNS, 12028325, 11032531, 12033030, B36CL80ENS, WFC100MF, WFS200MF, REPLFLTR55, REPLFTR50, 11041954, 11050659, RA450022

وارنٽي ۽ سپورٽ

Specific warranty details for the Pureline PL-5700 filter are not provided in the product information. For warranty claims or technical support, please refer to the contact information provided with your purchase or visit the PURELINE official webسائيٽ.
