1. تعارف
Thank you for choosing the BLUETTI Premium 200 V2 Portable Power Station. This device is engineered to provide reliable and versatile power for various applications, including camping, road trips, off-grid living, and home backup. With its advanced LFP battery technology and robust design, it offers a long lifespan and efficient power delivery.
اهم خاصيتون:
- اعليٰ گنجائش ۽ پيداوار: 2073.6Wh capacity with 2700W AC output (5400W peak), capable of powering up to 7 devices simultaneously.
- توسيع ٿيل عمر: Automotive-grade LiFePO4 batteries with 6000+ cycles, ensuring a 17-year lifespan, significantly longer than average.
- تيز چارجنگ: Features TurboBoost technology and built-in MPPT modules, allowing up to 80% charge in just 45 minutes with dual AC and DC charging.
- ڪمپيڪٽ ڊيزائن: Despite its high capacity, the Premium 200 V2 is designed to be ultra-compact and portable.
- سمارٽ ڪنٽرول: An upgraded app provides intuitive control and real-time power insights for seamless operation.
ڇا شامل آهي:
- BLUETTI پريميئم 200 V2 پورٽيبل پاور اسٽيشن
- اي سي چارجنگ ڪيبل
- شمسي چارج ڪيبل
- گرائونڊ اسڪرو
- استعمال ڪندڙ جو دستياب (ھي دستاويز)
Figure 1: BLUETTI Premium 200 V2 Portable Power Station.
2. حفاظتي هدايتون
Please read and understand all safety instructions before operating the BLUETTI Premium 200 V2. Failure to follow these instructions may result in electric shock, fire, or serious injury.
- حصو نه جدا ، مرمت ، يا تبديل ڪريو.
- يونٽ کي باهه جي ويجهو نه رکو يا ان کي گرميءَ جي سامهون نه رکو.
- يونٽ کي غسل خاني ۾ يا پاڻي يا مينهن جي سامهون واري علائقي ۾ استعمال يا ذخيرو نه ڪريو.
- جيڪڏهن يونٽ خراب ٿي ويو آهي يا ڪري پيو آهي ته ان کي استعمال نه ڪريو.
- يونٽ کي ٻارن ۽ پالتو جانورن جي پهچ کان پري رکو.
- استعمال ۽ چارجنگ دوران مناسب وينٽيليشن کي يقيني بڻايو وڃي ته جيئن وڌيڪ گرم ٿيڻ کان بچي سگهجي.
- صرف BLUETTI-منظور ٿيل لوازمات ۽ چارجنگ ڪيبل استعمال ڪريو.
- آئوٽ پُٽ پورٽن کي شارٽ سرڪٽ ڪرڻ کان پاسو ڪريو.
- بندرگاهن يا کليل خانن ۾ غير ملڪي شيون داخل نه ڪريو.
- يونٽ ۽ ان جي بيٽري کي مقامي ضابطن مطابق ختم ڪريو.
3. پراڊڪٽ ختمview
The BLUETTI Premium 200 V2 features a user-friendly interface and multiple output ports to accommodate various devices. Familiarize yourself with the components before operation.
اجزاء جي سڃاڻپ:
- LCD ڊسپلي: Shows battery level, input/output power, and operational status.
- ڊي سي ان پٽ پورٽ: For charging via solar panels or car charger.
- AC ان پٽ پورٽ: For charging via wall outlet.
- AC Output Outlets: Standard 120V AC outlets for household appliances.
- USB-A بندرگاهن: For charging smaller electronic devices.
- USB-C بندرگاهن: High-speed charging for compatible devices.
- Car Port (12V/10A): For powering 12V DC devices.
- پاور بٽڻ: يونٽ کي آن/آف ڪرڻ لاءِ.
Figure 2: The BLUETTI Premium 200 V2 powering devices in an outdoor setting.
4. سيٽ اپ
شروعاتي چارج:
Before first use, fully charge your BLUETTI Premium 200 V2. It is recommended to charge the unit to 100% upon receipt.
- AC چارجنگ: Connect the provided AC charging cable to the AC input port on the unit and then to a wall outlet. The unit supports 1800W AC charging, reaching 80% in approximately 45 minutes.
- شمسي چارج: Connect compatible solar panels (up to 1000W) to the DC input port using the solar charging cable. The built-in MPPT controller optimizes charging efficiency from sunlight. Full charge from solar can take approximately 2.4 hours under optimal conditions.
- ڪار چارج ڪرڻ: Connect the car charging cable to the DC input port and your vehicle's 12V cigarette lighter outlet.
- Dual Charging (AC + Solar): For the fastest charging, combine AC and solar input for a maximum of 2400W. This can charge the unit to 80% in about 50 minutes.
Figure 3: Various charging methods for the power station.
5. آپريٽنگ هدايتون
پاور آن / آف:
Press and hold the main power button for a few seconds to turn the unit on or off. The LCD display will illuminate.
اي سي آئوٽ پُٽ استعمال ڪندي:
Press the AC power button to enable the AC outlets. Plug your devices into the 120V AC outlets. The unit provides 2700W continuous power and 5400W peak power. For resistive loads, the Power Lifting mode can provide up to 3900W.
Using DC Output:
Press the DC power button to enable the USB-A, USB-C, and 12V car port outputs. Connect your devices to the appropriate ports.
ائپ ڪنٽرول:
Download the BLUETTI app from your smartphone's app store. Connect the power station via Bluetooth to monitor real-time power insights, adjust settings, and control outputs remotely. The app supports features like peak cutting and valley filling modes for optimized energy usage.
Uninterrupted Power Supply (UPS) Function:
When connected to an AC wall outlet, the Premium 200 V2 can function as an Uninterrupted Power Supply (UPS). In case of a power outage, it automatically switches to battery power within 15ms, ensuring continuous operation for connected devices like computers or refrigerators.
Figure 4: The power station supports various everyday power needs.
6. سار سنڀال
Proper maintenance ensures the longevity and optimal performance of your BLUETTI Premium 200 V2.
- صفائي: Use a dry, soft cloth to wipe the unit. Do not use abrasive cleaners or solvents.
- اسٽوريج: If storing for an extended period, charge the unit to 50-80% every 3-6 months. Store in a cool, dry place away from direct sunlight and extreme temperatures.
- بيٽري جي سنڀال: The LiFePO4 battery is designed for durability. Avoid fully discharging the battery frequently to maximize its lifespan.
- وينٽيليشن: پڪ ڪريو ته وينٽيليشن جا دروازا مٽي ۽ ملبي کان پاڪ آهن ته جيئن وڌيڪ گرم ٿيڻ کان بچي سگهجي.
7. مسئلا حل ڪرڻ
If you encounter issues with your BLUETTI Premium 200 V2, refer to the following common problems and solutions:
| مسئلو | ممڪن سبب | حل |
|---|---|---|
| يونٽ چالو نه آهي | بيٽري مڪمل طور تي ختم ٿي وئي آهي؛ پاور بٽڻ ڪافي دير تائين نه دٻايو ويو آهي. | Charge the unit using AC power; Press and hold the power button for 3-5 seconds. |
| ڪابه AC ٻاھر نه | AC output not enabled; Overload protection activated; Device power exceeds unit capacity. | Press the AC power button; Reduce connected load; Check device wattage. |
| ڪابه ڊي سي آئوٽ | DC output not enabled; Overload protection activated. | Press the DC power button; Reduce connected load. |
| سست چارج | Using low-power charging method; Environmental factors (solar). | Use AC charging or dual charging; Ensure solar panels are in direct sunlight and clean. |
| ايپ ڪنيڪشن مسئلا | Bluetooth off; App not updated; Unit too far from phone. | Ensure Bluetooth is enabled on phone and unit; Update app; Move closer to the unit. |
If the problem persists after trying these solutions, please contact BLUETTI customer support.
8. وضاحتون
Detailed technical specifications for the BLUETTI Premium 200 V2 Portable Power Station:
| خاصيت | تفصيل |
|---|---|
| برانڊ | بلوٽي |
| ماڊل نالو | پريميئم 200 V2 |
| بيٽري جو قسم | LiFePO4 (ليتيم آئرن فاسفيٽ) |
| بيٽري جي گنجائش | 2073.6 واٽ-ڪلاڪ (Wh) |
| ڄمار | 6000+ cycles to 80% original capacity (approx. 17 years) |
| AC ٻاھر | 2700 واٽ (درجه بندي)، 5400 واٽ (چوٽي) |
| پاور لفٽنگ موڊ | 3900 Watts (for resistive loads) |
| ڪُل اي سي آئوٽليٽس | 2 |
| ڊي سي اوٽ | 1 x Car Port (12V/10A), 2 x USB-A (15W), 2 x USB-C (100W) |
| AC چارجنگ ان پٽ | 1800 واٽ و Max |
| شمسي چارجنگ ان پٽ | 1000 Watts Max (12V-60V/20A) |
| Max Combined Input (AC+Solar) | 2400 واٽ |
| UPS سوئچنگ وقت | <15ms |
| پيداوار جي ماپ (L x W x H) | 13.8" x 9.9" x 12.8" |
| شيءِ جو وزن | 53.4 پائونڊ |
9. وارنٽي ۽ سپورٽ
BLUETTI stands behind the quality of its products. The Premium 200 V2 Portable Power Station comes with a comprehensive warranty to ensure your peace of mind.
وارنٽي ڄاڻ:
The BLUETTI Premium 200 V2 is covered by a 5 سال وارنٽي. هي وارنٽي عام استعمال هيٺ مواد ۽ ڪاريگري ۾ خرابين کي ڍڪيندي آهي. وارنٽي دعوائن لاءِ مهرباني ڪري خريداري جو ثبوت رکو.
Figure 5: Automotive-grade LiFePO4 battery with 5-year coverage.
ڪسٽمر سپورٽ:
BLUETTI is committed to providing excellent after-sale service. If you have any questions, require technical assistance, or need to make a warranty claim, please contact our support team through the following channels:
- Webسائيٽ: سرڪاري BLUETTI جو دورو ڪريو webسوالن، سپورٽ وسيلن، ۽ رابطي جي فارمن لاءِ سائيٽ.
- اي ميل: support@bluetti.com
- فون: Refer to the contact information provided on the official BLUETTI website or in your product packaging for regional support numbers.
Our widespread sales and after-service networks are available to assist you.
